Nordic APIs OAuth Workshop, Amsterdam June 2017

2017-06-12 (Monday) | 1000 words (~5 minutes reading)

Notes to myself.

In June I attended [Nordic API’s workshop](http://nordicapis.com/events/nordic- apis-workshops-amsterdam/) on OAuth and OpenID in Amsterdam. Here are my notes on the class.

Actors in OAuth

AS: Authorisation Server (OAuth Server), e.g. bank auth server
RS: Resource Server, e.g. bank account server
RO: Resource Owner, e.g. bank customer
C: Client, e.g. mobile app

OAuth is designed for cross-organisational authorisation, i.e. where the client is not trusted (which should always be the case). The AS and RO do not want to let the client nor the resource server have access to the RO’s credentials.

A client could be provided by a completely separate organisation, e.g. a third- party Twitter app. The resource server should not be concerned with the details of users, just performing their requested actions. In this way, OAuth is not an authorisation protocol, but a delegation protocol.

OAuth code flow

The standard and recommended oauth flow uses an authentication code approach:

RO asks client to do something.
Client makes GET request to authorisation endpoint on AS, with the required scope (e.g. “read balance” or “transfer money”).
AS responds with a 3xx response to send client to authentication endpoint.
After authentication, a one-time auth code (a grant) is given to the client.
Client makes a POST request to the token endpoint with the grant and a client secret.
After checking grant and secret, AS responds with an access token (AT) and a refresh token (RT).
Client makes the request for the original action to RS with this header: Authorization: Bearer {AT}.

Example OAuth code flow requests and responses

Authorise:

GET /oauth/v2/authorize?client_id=client-1&amp;scope=read&amp;response_type=code HTTP/1.1
Host: auth.example.com

...

HTTP/1.1 301 Moved Permanently
Location: https://app.other-example.com/callback?code=L8ZKjO2TTVbg1hghhM15EvvA23

Token:

POST /oauth/v2/token HTTP/1.1
Host: auth.example.com
Content-Type: application/x-www-form-urlencoded

grant_type=authorization_code&client_id=client-1&client_secret=Password1
&code=L8ZKjO2TTVbg1hghhM15EvvA23

...

HTTP/1.1 200 OK

{
    "access_token": "b4ff0851-b0a1-4ea3-a04a-8b997bf83079",
    "scope": "",
    "token_type": "bearer",
    "expires_in": 300
}

Resource server call:

GET /hello_world HTTP/1.1
Host: resource.example.com
Authorization: Bearer b4ff0851-b0a1-4ea3-a04a-8b997bf83079

...

HTTP/1.1 200 OK

<xml>Here's your sensitive data</xml>

OpenID Connect

OpenId Connect is built on top of OAuth and adds an identity layer.

In the initial request to the AS, the scope is set to openid. After authentication, the AS providers an id token (IT) along with the AT and RT.

The IT is a JSON document with information about:

identity
authentication method
client it was issued for (audience)

The IT is a signed JWT. The client can use the public key of the AS to verify it.

No information beyond identity should be stored in the JWT, as it is not there to provide any extraneous data to the client. It should be for authorisatiom and identification only.

OAuth introspection

An endpoint on e.g. /oauth/v2/introspect. The client sends the access token and client id and the AS responds with an identity document similar to a JWT but unsigned, e.g.

{
	"active": true,
	"scope": "read write email",
	"client_id": "foobar_id",
	"username": "joebloggs",
	"exp": 1497269423
}

This is used to check if the token the client has is valid, and what it is for.

Refreshing OAuth tokens

Access tokens are usually short-lived, e.g. 30 seconds or 5 minutes. To avoid repeatedly authenticating the user, we can use the refresh token.

The client calls the /token endpoint again, e.g.:

POST /oauth/v2/token HTTP/1.1
Content-Type: application/x-www-form-urlencoded

grant_type=refresh_token&client_id=fooclient&client_secret=foosecret
&refresh_token=foobar123

...

HTTP/1.1 200 OK

{
	"access_token": "access123",
	"refresh_token": "refresh123",
	"token_type": "bearer",
	"expires_in": 300
}

Each refresh token can only be used once, and may only be used by the client it was granted to.

JWK: JSON Web Key

JWK is a [JSON format](https://self-issued.info/docs/draft-ietf-jose-json-web- key.html) for sending cryptographic keys.

{
	"kty":"EC",
	"crv":"P-256",
	"x":"f83OJ3D2xF1Bg8vub9tLe1gHMzV76e8Tus9uPHvRVEU",
	"y":"x_FEzRu9m36HLN_tue659LNpXW6pCyStikYjKIWI5a0",
	"kid":"Public key used in JWS spec Appendix A.3 example"
}

Implicit grant

An implicit flow is used for an application that is unable to keep a secret. For example, a backend server is a private client as it can securely store a secret, whilst a frontend JavaScript application is a public client as it cannnot securely store the secret.

Such a client can make a request to the /authorise endpoint, and gets back an access token directly as part of the redirect URL, but no refresh token. The access token is included in the fragment part of the URL, so that only the client has access to it (the fragment is not sent to servers).

Client-only flow

There is also a flow for [client-only authentication](http://oauthlib.readthedoc s.io/en/latest/oauth2/grants/credentials.html), e.g. a cronjob process that acts on its own and not on behalf of a resource owner (user).

Such a client can send a request to the /token endpoint, e.g.:

POST /oauth/v2/token HTTP/1.1
Content-Type: application/x-www-form-urlencoded

grant_type=read&client_id=fooclient&client_secret=foosecret

...

HTTP/1.1 200 OK

{
	"access_token": "access123",
	"subject": "fooclient",
	"client_id": "fooclient",
	"token_type": "bearer",
	"expires_in": 300
}

Notice that the subject and client_id are the same in this response. No refresh token is provided, as this kind of client can simply re-authenticate whenever it needs to.

This flow should only be used by private, pre-trusted clients that are able to securely store the access token.

Resource owner credentials flow

This flow is for situations where the resource owner trusts the client (e.g. their operating system, and not some third-party app). Because of this pre- trust, this flow is not ideal and should only be used when other flows are not possible.

The client collects the credentials from the resource owner and sends them to the AS itself, with a grant_type of password. This is dangerous because the client gets to see the credentials (vs only ever getting tokens in the standard code-based flow above).

The AS then responds with an access token as usual. This way at least the resource server does not see the RO credentials, only the client and AS.

Exercises

https://github.com/curityio/nordicapis-python-openid-connect-client https://github.com/curityio/oauth-filter-for-python-flask
