Creating AWS Organizational Units and Accounts for Prod and Dev in CloudFormation

2024-10-05 (Saturday) | 400 words (~2 minutes reading)

Here’s an AWS CloudFormation template and deployment script to set up Organizational Units and Accounts for Prod and Dev for a new project or department.

Deploying a CloudFormation stack from this template will require a user in the Organization’s management account with the AdministratorAccess permission set.

The created Organizational Unit (OU) and Account structure will look this:

Organization Root [pre-existing]

  ╚═ Management Account [pre-existing]

  ╚═ Project Parent OU

     ╚═ Project Prod OU

        ╚═ Project Prod Account

     ╚═ Project Dev OU

        ╚═ Project Dev Account

The OUs are not strictly necessary, but they help to group the whole project under a single OU, and to allow for other accounts to be added later within the Prod and Dev OUs if necessary.

The CloudFormation template looks like this:

---
AWSTemplateFormatVersion: '2010-09-09'
Description: >
  Create AWS Organizational Units and an Accounts for a project.

# https://docs.aws.amazon.com/AWSCloudFormation/latest/UserGuide/aws-resource-organizations-organizationalunit.html
# https://docs.aws.amazon.com/AWSCloudFormation/latest/UserGuide/aws-resource-organizations-account.html

Parameters:

  OrganizationRootId:
    Type: String
    Description: ID of the root Organization of the management account.
    AllowedPattern: "^(r-[0-9a-z]{4,32})$"

  ProjectName:
    Type: String
    Description: Overall name for this project, used in OU and Account names.
    AllowedPattern: "^([a-zA-Z]+)$"

  EmailDomain:
    Type: String
    Description: Domain name for AWS Account email addresses.
    AllowedPattern: "^([a-zA-Z0-9]+).([a-zA-Z0-9\.]+)$"

Resources:

  ProjectParentOrganizationalUnit:
    Type: AWS::Organizations::OrganizationalUnit
    Properties:
      Name: !Sub "${ProjectName}ParentOU"
      ParentId: !Ref OrganizationRootId

  ProdOrganizationalUnit:
    Type: AWS::Organizations::OrganizationalUnit
    Properties:
      Name: !Sub "${ProjectName}ProdOU"
      ParentId: !Ref ProjectParentOrganizationalUnit

  ProdAccount:
    Type: AWS::Organizations::Account
    Properties:
      AccountName: !Sub "${ProjectName}Prod"
      Email: !Sub "${ProjectName}_aws_prod@${EmailDomain}"
      RoleName: !Sub "${ProjectName}ProdAdmin"
      ParentIds:
        - !Ref ProdOrganizationalUnit

  DevOrganizationalUnit:
    Type: AWS::Organizations::OrganizationalUnit
    Properties:
      Name: !Sub "${ProjectName}DevOU"
      ParentId: !Ref ProjectParentOrganizationalUnit

  DevAccount:
    Type: AWS::Organizations::Account
    Properties:
      AccountName: !Sub "${ProjectName}Dev"
      Email: !Sub "${ProjectName}_aws_dev@${EmailDomain}"
      RoleName: !Sub "${ProjectName}DevAdmin"
      ParentIds:
        - !Ref DevOrganizationalUnit

Outputs:

  ProjectParentOrganizationalUnitArn:
    Description: ARN of the Project Parent Organizational Unit
    Value: !GetAtt ProjectParentOrganizationalUnit.Arn

  ProdOrganizationalUnitArn:
    Description: ARN of the Prod Organizational Unit
    Value: !GetAtt ProdOrganizationalUnit.Arn

  ProdAccountArn:
    Description: ARN of the Prod Account
    Value: !GetAtt ProdAccount.Arn

  DevOrganizationalUnitArn:
    Description: ARN of the Dev Organizational Unit
    Value: !GetAtt DevOrganizationalUnit.Arn

  DevAccountArn:
    Description: ARN of the Dev Account
    Value: !GetAtt DevAccount.Arn

Here’s a sample deployment script to deploy the above template:

#!/usr/bin/env bash

set -e, -u, -x, -o pipefail

PARENT_PATH=$( cd "$(dirname "${BASH_SOURCE[0]}")" || exit; pwd -P )
TEMPLATE_PATH="${PARENT_PATH}/cloudformation.yml"
PARAMS_PATH="${PARENT_PATH}/config/organizational.params"

ls "${TEMPLATE_PATH}"
if [ ! -f "${TEMPLATE_PATH}" ]; then
  echo "Cloudformation template file is missing"
fi

ls "${PARAMS_PATH}"
if [ ! -f "${PARAMS_PATH}" ]; then
  echo "Params file is missing"
fi

if [ -z ${AWS_PROFILE+x} ]; then
  echo "AWS_PROFILE is not set"
  exit 1
fi

# shellcheck disable=SC1090
source "${PARAMS_PATH}"

if [ -z ${OrganizationRootId+x} ]; then
  echo "OrganizationRootId is not set"
  exit 1
fi

# shellcheck disable=SC2154
echo "OrganizationRootId: ${OrganizationRootId}"
# shellcheck disable=SC2154
echo "ProjectName: ${ProjectName}"

# https://docs.aws.amazon.com/cli/latest/reference/cloudformation/deploy/

# shellcheck disable=SC2046

aws cloudformation deploy \
  --profile "${AWS_PROFILE}" \
  --template-file "${PARENT_PATH}/cloudformation.yml" \
  --stack-name "${ProjectName}-Organizational" \
  --parameter-overrides OrganizationRootId="${OrganizationRootId}" $(cat "${PARAMS_PATH}")

That requires a params file at ./config/organizational.params, which provides the ProjectName and EmailDomain params, for example:

ProjectName=FoobarProject
EmailDomain=kensiosoftware.co.uk

This assumes that a catch-all email is set up on the specified domain, so that the CloudFormation template can make up specific email addresses for each account.
